10m cable duct 100x60 white VDE with clips

PVC cable duct, for wall and ceiling mounting with clips 10 m cable duct 100x60 mm (5 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clips are included, 3 per 2m.Certification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 10 Meter (€6.92* / 1 Meter)

€69.15*

10m cable duct 80x60 mm white VDE

Cable duct made of PVC, new product! with VDE certification 10m cable duct 80x60 mm (5 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clamps are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 10 Meter (€4.99* / 1 Meter)

€49.90*

2m cable duct 100x40 white VDE with clips

PVC cable duct, for wall and ceiling mounting with clips 2m cable duct 100x40 mmColour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clips are included, 3 per 2m.Certification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 2 Meter (€5.95* / 1 Meter)

€11.90*

2m cable duct 30x25 mm white VDE

PVC cable duct, for wall and ceiling mounting 2 m cable duct 30x25 mm Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clips are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 2 Meter (€2.50* / 1 Meter)

€5.00*

%

10m cable duct 80x40 mm white VDE

Cable duct made of PVC, new product! with VDE certification 10m cable duct 80x40 mm (5 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clamps are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.7 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 10 Meter (€4.69* / 1 Meter)

€46.90* €50.50* (7.13% saved)

10m cable duct 40x40 White VDE

Cable duct made of PVC, new product! with VDE certification 10m cable duct 40x40 mm (5 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clamps are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.7 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 10 Meter (€3.58* / 1 Meter)

€35.80*

10m cable duct 60x60 White VDE

PVC cable duct, for wall and ceiling mounting 10 m cable duct 60x60 mm (5 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clamps are not included Certification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 10 Meter (€4.88* / 1 Meter)

€48.80*

20m cable duct 30x30 white VDE

PVC cable duct, for wall and ceiling mounting 20 m cable duct 30x30 mm (10 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clamps are not included Certification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 20 Meter (€1.64* / 1 Meter)

€32.80*

2m cable duct 100x60 white VDE with clips

PVC cable duct, for wall and ceiling mounting with clips 2 m cable duct 100x60 mmColour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clips are included, 3 per 2m.Certification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 2 Meter (€8.45* / 1 Meter)

€16.90*

10m cable duct 100x40 White VDE

Cable duct made of PVC, new product! with VDE certification 10m cable duct 100x40 mm (5 pieces per 2 m)Colour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clamps are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and the associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 10 Meter (€5.08* / 1 Meter)

€50.80*

Details

2m cable duct 80x40 mm white VDE

PVC cable duct, new product! with VDE certification 2m cable duct 80x40 mmColour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clips are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 2 Meter (€7.49* / 1 Meter)

€14.98*

%

2m cable duct 80x60 mm white VDE

PVC cable duct, new product! with VDE certification 2m cable duct 80x60 mmColour: White RAL 9016With base perforation and coverProtection class: IP40, flame-retardant, self-extinguishingCable clips are not includedCertification: VDE, ID no. 40031254 DIN EN 50085-1 (VDE 0604-1):206-03; EN 50085-1:2005DIN EN 50085-2-1 (VDE 0604 Part 2-1):2012-09; EN 50085-2-1:2006 + A1:20111 **Essential features** PVC cable trunking and associated accessories are manufactured from PVC raw material of class M1 (non-combustible).2 **UV light resistance** After exposure to 300 W UV light for 28 days, PVC trunking and accessories showed no change in colour or appearance.3 **Colours** PVC cable trunking and accessories are available in the colour RAL 9016.4 **Resistance to acid vapour** PVC cable trunking and accessories were exposed to hydrochloric acid and sulphuric acid vapours for 3 hours. No change in surface or colour was observed after this period.5 **Cold and heat resistance** PVC cable trunking and accessories were subjected to thermal tests at temperatures of -5 °C and +60 °C for 72 hours. No cracks, swelling, flaking or deformation occurred.6 **Colourability** The dyeability of the samples was tested with water- and solvent-based colours. It was found that the samples could be coated with both types of colours.

Content: 2 Meter (€8.40* / 1 Meter)

€16.80* €19.55* (14.07% saved)

Details

1
2
3

5% discount for orders over €5000

Subscribe to the newsletter to receive the latest discount codes.

Free shipping to Germany

for orders over €500

Free shipping to Austria, Belgium and Netherlands

for orders over €1000

White Cable Trunking & Cable Ducts – Professional PVC Solutions Compliant with BS EN 50085

Our white cable trunking (also known as white cable ducts or white cable channels) provides a safe, neat, and professional way to manage and protect power, data, and communication cables. Designed for electricians, electrical contractors, construction companies, renovation firms, industrial facilities, research centres, and van conversion specialists, these PVC trunking systems ensure mechanical protection, fire safety, and a clean aesthetic finish in RAL 9016 white.

All our white cable trunking systems comply with the latest standards: BS EN 50085-1 (general requirements) and BS EN 50085-2-1 (wall and ceiling trunking systems), offering reliable performance for surface-mounted installations.

Key Benefits of High-Quality White Cable Trunking

White cable trunking offers an unobtrusive, modern appearance that blends seamlessly into most interiors. It can often be painted to match surroundings and helps eliminate trip hazards by keeping cables organised and protected from dust, mechanical damage, and environmental factors.

High mechanical strength and long-term durability
Flame-retardant, self-extinguishing material (Class V0 / M1 equivalent)
Temperature range: -5°C to +60°C
UV-stabilised versions available for improved weather resistance
Acid and chemical resistant – suitable for demanding environments
Easy to cut, paint, and install with self-adhesive or screw-fix options

Applications for White Cable Trunking

White cable trunking is the preferred choice for professional, norm-compliant, and visually clean cable management across many sectors:

Electrical Installations & Professional Electricians

Ideal for surface-mounted routing of power and data cables in commercial and residential buildings – delivering safety, accessibility, and a tidy appearance without chasing walls.

Construction & Renovation Projects

Perfect for new builds, refurbishments, and retrofits where quick, clean installations are required without major structural work.

Industrial & Manufacturing Facilities

Provides robust protection in factories and workshops against dust, mechanical stress, and chemical exposure for complex machine and equipment wiring.

Van Conversions & Mobile Installations

Vibration-resistant and space-efficient solution for vehicle electrics in campervans, commercial vans, and mobile units – ensuring neat, serviceable cable runs.

Research Centres & Laboratories

Chemical-resistant properties make them suitable for technical labs, test benches, and sensitive environments with potential acid or solvent exposure.

Outdoor & Protected External Use

UV-resistant models are suitable for weather-protected applications such as EV chargers (Wallbox), external lighting, heat pumps, and other outdoor electrical setups.

Available Sizes of White Cable Trunking

Dimensions (W × H in mm)	Typical Applications	Key Features
30 × 25 mm	Small cable bundles, offices, lighting	Compact, often self-adhesive
30 × 30 mm / 40 × 40 mm	Multiple power & data cables	Versatile for light to medium installations
60 × 60 mm	Commercial & light industrial	Good capacity with sturdy build
80 × 40 mm / 80 × 60 mm	Larger cable volumes	Flat or deeper profile for flexibility
100 × 40 mm / 100 × 60 mm	Heavy-duty industrial & commercial runs	High capacity, excellent for dense cabling

Frequently Asked Questions about White Cable Trunking (FAQ)

What is white cable trunking and what is it used for?

White cable trunking (also called white cable duct or white cable channel) is a PVC system designed for the organised, protected surface mounting of electrical cables on walls or ceilings. It ensures safety, easy maintenance, and a professional finish in commercial, industrial, and residential environments.

Is white cable trunking UV resistant and suitable for outdoor use?

Yes – selected versions are UV-stabilised and tested for outdoor performance. They show no significant colour or material degradation under prolonged UV exposure, making them suitable for protected external applications such as EV charging points or external lighting.

What sizes are available for white cable trunking?

Common sizes range from compact 30×25 mm up to larger 100×60 mm profiles. The right size depends on the number and cross-section of cables – smaller for office or domestic use, larger for industrial applications.

Do the cable trunking systems comply with BS EN 50085?

Yes. All our white PVC cable trunking meets the requirements of BS EN 50085-1 (general requirements) and BS EN 50085-2-1 (wall and ceiling mounting systems), ensuring full compliance with current European and UK standards (superseding older BS 4678).

Are white cable trunking systems fire retardant or heat resistant?

They are manufactured from self-extinguishing, flame-retardant PVC material and are suitable for temperatures from -5°C to +60°C, meeting high fire safety standards required in professional installations.

How do you install white cable trunking?

Installation is straightforward: clean the mounting surface, align the base, fix using self-adhesive backing or screws/clips, lay the cables, and snap on the lid. A full range of accessories (connectors, elbows, end caps, dividers) allows complete professional systems.

Is white cable trunking suitable for industrial and laboratory environments?

Absolutely. Its mechanical strength, dust protection, and chemical resistance make it ideal for factories, workshops, and research facilities.

Can white cable trunking be painted?

Yes – it accepts most water-based and solvent-based paints, allowing perfect colour matching to walls or interiors.

What accessories are available for white cable trunking?

A comprehensive selection including internal/external corners, flat angles, couplers, end caps, cable dividers, and fixing clips – everything needed for a complete, standards-compliant installation.

Why choose white cable trunking over other colours?

White (RAL 9016) is discreet, modern, and blends into most environments. It is the most popular choice among electricians, builders, and renovators for its clean, professional appearance.
