SALE remaining stock

Erdkabel NYY-J 5x6, 5x10, 5x1,5 mm² Schwarz 50m Ring

Underground cable NYY-J 5x10 mm² black 10m

- 10m ring NYY-J 5x10 PVC power cable to DIN VDE 0279 Part 603 - Conductor material: CU, bare - Outer diameter: approx. 21mm- Conductor class: class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 10 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature permanently installed: +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 10 Meter (€6.89* / 1 Meter)

€68.90* €74.90* (8.01% saved)

NYY-J 5x10 mm² underground cable 24m

- 24m ring NYY-J 5x10 PVC power cable to DIN VDE 0279 Part 603 - Conductor material: CU, bare - Outer diameter: approx. 21 mm- Conductor class: class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 10 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature permanently installed: +70°C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 24 Meter (€7.00* / 1 Meter)

€167.94* €176.20* (4.69% saved)

NYY-J 5x10 mm² underground cable 29m

- 29m ring NYY-J 5x10 PVC power cable to DIN VDE 0279 Part 603 - Conductor material: CU, bare - Outer diameter: approx. 21 mm- Conductor class: class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 10 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature permanently installed: +70°C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 29 Meter (€7.00* / 1 Meter)

€202.93* €213.07* (4.76% saved)

Underground cable NYY-J 5x4 mm² black 34m

- 34m ring NYY-J 5x4 PVC power cable to DIN VDE 0279 Part 603 - Conductor material: CU, bare - Outer diameter: approx. 15.5 mm- Conductor class: class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 4 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature in fixed installation: +70°C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 34 Meter (€3.12* / 1 Meter)

€106.08* €111.38* (4.76% saved)

Mantelleitung NYM-J von 1,5 mm² bis 16 mm²

NYM-J 5x6 mm² sheathed cable 11m

- 11m ring NYM-J 5x6 PVC installation cable to DIN VDE 0250 Part 204- Outer diameter: approx. 15.5 mm - Conductor material: Cu, bare- Conductor class: Class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 6 mm² - Sheath colour: grey (RAL 7035) - Flame resistance: in accordance with VDE 0482-332-1-2 - Permissible external cable temperature permanently installed: -40 - +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: U0/U 300/500 V - Test voltage: 2 kV

Content: 11 Meter (€3.92* / 1 Meter)

€43.07* €45.22* (4.75% saved)

Tip

Underground cable NYY-J 5x6 mm² black 29m

- 29m ring NYY-J 5x6 PVC power cable in accordance with DIN VDE 0276-603 (VDE 0276-603):2010-03; HD 603 S1:1994/A3:2007- Conductor material: CU, bare - Outer diameter: approx. 17 mm- Conductor class: class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 6 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature permanently installed: +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 29 Meter (€4.56* / 1 Meter)

€132.11* €138.72* (4.76% saved)

NYM-J 5x10 mm² sheathed cable 12m

- 12m ring NYM-J 5x10 PVC installation cable to DIN VDE 0250 Part 204- Outer diameter: approx. 18.5 mm - Conductor material: Cu, bare- Conductor class: Class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 10 mm² - Sheath colour: grey (RAL 7035) - Flame resistance: in accordance with VDE 0482-332-1-2 - Permissible external cable temperature permanently installed: -40 - +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: U0/U 300/500 V - Test voltage: 2 kV

Content: 12 Meter (€7.29* / 1 Meter)

€87.50* €91.87* (4.76% saved)

NYM-J 5x4 mm² sheathed cable 26m

- 26m ring NYM-J 5x4 PVC installation cable to DIN VDE 0250 Part 204- Outer diameter: approx. 14.5 mm - Conductor material: Cu, bare- Conductor class: Class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 4 mm² - Sheath colour: grey (RAL 7035) - Flame resistance: in accordance with VDE 0482-332-1-2 - Permissible external cable temperature permanently installed: -40 - +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: U0/U 300/500 V - Test voltage: 2 kV

€80.82* €84.86* (4.76% saved)

NYM-J 5x4 mm² sheathed cable, 7m

- 7m ring NYM-J 5x4 PVC installation cable to DIN VDE 0250 Part 204- Outer diameter: approx. 14.5 mm - Conductor material: Cu, bare- Conductor class: Class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 4 mm² - Sheath colour: grey (RAL 7035) - Flame resistance: in accordance with VDE 0482-332-1-2 - Permissible external cable temperature permanently installed: -40 - +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: U0/U 300/500 V - Test voltage: 2 kV

Content: 7 Meter (€3.11* / 1 Meter)

€21.75* €22.83* (4.73% saved)

NYY-J 5x10 mm² underground cable 12m

- 12m ring NYY-J 5x10 PVC power cable to DIN VDE 0279 Part 603 - Conductor material: CU, bare - Outer diameter: approx. 21 mm- Conductor class: class 1 (solid) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 10 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature permanently installed: +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 12 Meter (€7.00* / 1 Meter)

€83.97* €88.21* (4.81% saved)

Underground cable NYY-J 5x16 mm² black 18m RM

- 18m ring NYY-J 5x16 PVC power cable to DIN VDE 0279 Part 603 - Conductor material: CU, bare - Outer diameter: approx. 24 mm- Conductor class: class 2 (solid) RM- Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 16 mm² - Sheath colour: black - Flame retardancy: according to VDE 0482-332-1-2/IEC 60332-1 - Permissible operating temperature: at conductor 70°C - Permissible external cable temperature permanently installed: +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: u0/u 0.6/1 kV - Test voltage: 4 kV

Content: 18 Meter (€16.31* / 1 Meter)

€293.56* €308.23* (4.76% saved)

NYM-J 5x16 mm² sheathed cable 26m

Attention! Forwarding agent dispatch. Delivery time 3-5 days. Please make sure that your telephone number and email address are correct. A delivery date will be agreed when the appointment is made by telephone.- 26m ring NYM-J 5x16 PVC installation cable according to DIN VDE 0250 part 204 - Outer diameter: approx. 24 mm- Conductor material: Cu, bare- Conductor class: Class 1 (stranded) - Number of cores: 5 - Core labelling: according to VDE 0293 - Conductor nominal cross-section: 16 mm² - Sheath colour: grey (RAL 7035) - Flame resistance: in accordance with VDE 0482-332-1-2 - Permissible external cable temperature permanently installed: -40 - +70 °C - Permissible external cable temperature in motion: -5 - +70 °C - Rated voltage: U0/U 300/500 V - Test voltage: 2 kV

Content: 26 Meter (€11.73* / 1 Meter)

€305.09* €320.34* (4.76% saved)

Sale: Erdkabel und Mantelleitungen Restposten – Top Qualität und attraktive Preise mit schnellem Versand

Entdecken Sie unsere hochwertigen Restposten von Erdkabeln und Mantelleitungen, die für ihre Langlebigkeit und Flexibilität geschätzt werden. Diese Produkte sind ideal für die sichere Verlegung von Kabeln im Außenbereich. Greifen Sie zu und sichern Sie sich die besten Angebote für eine zuverlässige Verkabelung in Ihrem Projekt.
